Tank Merkava MK 4 3D Printing Model | Assembly

(11)
cm: 16.4 w x 29.5 d x 10.6 h
in: 6.457 w x 11.614 d x 4.173 h

Source Files

|

Description

|

Printing Details

This 3D model of Merkava MK 4 consists of files in StereoLithography (.Stl) format that is optimized for 3D printing.

Before printing the files, we strongly recommend reading the PRINTING DETAILS section.

WHAT WILL YOU GET AFTER PURCHASE?

  • 3 versions of Merkava MK 4 STL files for FFF/FDM and DLP/SLA - files for all versions are available for download after the purchase;
  • STL files of high-poly Merkava MK 4 Model for 3D printing consist of 267 files;
  • Sizes for:
  • FFF/FDM: 106 mm tall, 164 mm wide, 295 mm deep;
  • DLP/SLA: 79 mm tall, 115 mm wide, 211 mm deep;
  • Assembly Manual for FFF/FDM 2.0 and DLP/SLA 2.0 versions in PDF and video formats;
  • Detailed settings that we provide as a recommendation for Cura, Simplify3D, Slic3r and PrusaSlicer for the best print;
  • Full technical support from the Gambody Support Team.

Detailed information about this 3D printing model is available in the DESCRIPTION section.
