Jason Voorhees 3D Printing Figurine in Diorama | Assembly

(6)
cm: 23.4 w x 25.2 d x 31.2 h
in: 9.213 w x 9.921 d x 12.283 h

Source Files

|

Description

|

Printing Details

This 3D Figurine consists of files in StereoLithography (.Stl) format that have been optimized for 3D printing.

Before printing the files, we strongly recommend reading the PRINTING DETAILS section.

Jason Voorhees 3D Printing Figurine comes in 3 versions for each 3D printer type (FDM/FFF, DLP/SLA and SLS). Files for each version are available for download after the purchase.

Detailed information about this model is available in the DESCRIPTION section.

File Name File Size Time / Filament Object Size
(x/y/z mm)
1_Platform_1_FDM__repaire d.stl
26.21 MiB 48 h 5 min 27 m 118 x 161 x 68 Download
2_Platform_2_FDM__repaire d.stl
23.77 MiB 44 h 21 min 25 m 150 x 122 x 68 Download
3_Platform_3_FDM__repaire d.stl
23.87 MiB 40 h 53 min 23 m 144 x 112 x 71 Download
4_Platform_4_FDM__repaire d.stl
28.84 MiB 44 h 19 min 25 m 116 x 152 x 71 Download
5_Ge_lock_10H_(x19)_FDM _ repaired.stl
0.03 MiB 4 min <1 m 10 x 18 x 2 Download
6_Ge_lock_7S_(x5)_FDM rep aired.stl
0.02 MiB 3 min <1 m 7 x 18 x 2 Download
7_Platform_FDM__repaired. stl
41.04 MiB 164 h 16 min 87 m 234 x 234 x 71 Download
8_Jason_Head_1_FDM__repai red.stl
13.08 MiB 2 h 8 min 1 m 26 x 31 x 49 Download
9_Jason_Head_2_FDM__repai red.stl
21.27 MiB 2 h 48 min 2 m 26 x 33 x 51 Download
10_Jason_Body_FDM__repair ed.stl
60.25 MiB 16 h 23 min 10 m 69 x 51 x 99 Download
11_Jason_Arm_R_FDM__repai red.stl
18.08 MiB 4 h 47 min 3 m 64 x 52 x 59 Download
12_Jason_Arm_L_FDM__repai red.stl
24.50 MiB 2 h 14 min 1 m 31 x 37 x 72 Download
13_Jason_Pelvis_FDM__repa ired.stl
49.43 MiB 18 h 27 min 12 m 61 x 74 x 128 Download
14_Jason_Hand_R_FDM__repa ired.stl
2.99 MiB 48 min <1 m 19 x 16 x 42 Download
15_Machete_FDM__repaired. stl
6.33 MiB 30 min <1 m 80 x 77 x 11 Download
16_Jason_Boot_R_FDM__repa ired.stl
8.38 MiB 1 h 9 min 1 m 22 x 42 x 26 Download
17_Jason_Boot_L_FDM__repa ired.stl
8.37 MiB 1 h 6 min 1 m 25 x 42 x 26 Download
18_Corpse_Head_FDM__repai red.stl
12.97 MiB 3 h 6 min 2 m 35 x 34 x 77 Download
19_Corpse_Body_FDM__repai red.stl
27.62 MiB 11 h 7 min 7 m 58 x 58 x 77 Download
20_Corpse_Pelvis_FDM__rep aired.stl
20.49 MiB 7 h 16 min 4 m 53 x 46 x 63 Download
21_Corpse_Arm_R_FDM__repa ired.stl
11.06 MiB 2 h 17 min 1 m 25 x 35 x 72 Download
22_Corpse_Hand_R_FDM__rep aired.stl
4.58 MiB 43 min <1 m 19 x 22 x 34 Download
23_Corpse_Arm_L_FDM__repa ired.stl
12.11 MiB 1 h 33 min 1 m 28 x 20 x 71 Download
24_Corpse_Hand_L_FDM__rep aired.stl
4.55 MiB 38 min <1 m 21 x 15 x 34 Download
25_hand_L_empty_FDM (repa ired).stl
11.87 MiB 46 min <1 m 17 x 43 x 21 Download
...

HISTORY OF JASON VOORHEES

Jason Voorhees is the main antagonist of the Friday the 13th franchise. He was an almost completely silent, undead and unstoppable killing machine. Jason was an iconic madman who haunts Camp Crystal Lake and the surrounding area, driven to slaughter anyone he encounters by a burning need to avenge the death of his beloved mother, Pamela Voorhees. In this diorama is presented one of his victims with which he had already dealt with. The scene for the creation was taken from the film. Jason tore off the victim's legs and he drags it to his lake. This is one of the cruelest moments that completely conveys the whole essence of the character.

ABOUT THIS 3D FIGURINE

The model is saved in STL files, a format supported by most 3D printers

FDM version features:
- Contains 24 parts;
- Made with changable heads with mask and without it;
- Made with divided platform for any buildplate sizes;
- Made with Locks. One part of Lock (5_Ge_lock_10H_(x19)) you need to print 19 times, One part of Lock (6_Ge_lock_7S_(x5)) you need to print 5 times;
- All parts are divided in such way that you will print them with the smallest amount of supports.

DLP/SLA version features:
- Same as FDM but smaller, also made as 16 parts;

SLS version features:
- Same as SLA but made as 1 part in 2 variants for economy your material;

All STL files for 3D printing have been checked in Netfabb and no errors were shown.

Note: Before starting 3D printing the model, read the Printing Details for CURA 3.3.1. or Simplify3D softwares.

There are 24 parts for FFF/FDM version, 16 parts for DLP/SLA version and 2 parts for SLS.

Scale: Height of Jason is 1980 mm. The scale of this Scene was made in proportion to him: 1/8 for FDM version and 1/16 for SLS/SLA version.

FDM version dimensions:
After being printed will stand -  312 mm tall, 234 mm wide, 252 mm deep;

SLS/DLP/​SLA version dimensions:
After being printed will stand - 156 mm tall, 117 mm wide, 126 mm deep;
- Has a few details, to keep printing costs down.

WHAT WILL YOU GET AFTER PURCHASE?

- STL files of Jason Voorhees​ 3D Figurine in Diorama for 3D printing which consist of 42 parts;
- 3 versions of files for this model for FFF/FDM, DLP/SLA, and SLS;
- High-poly detailed figurine of the Jason Voorhees​;
- Detailed settings that we provide for Cura 3.3.1. and Simplify3D for the best print;
- Full technical support from the Gambody Support Team.

Watch the tutorial video on how to assemble Jason Voorhees​​ 3D Printing Figurine at Gambody YouTube channel.

You can get Model of Jason Voorhees​ for 3D Printing right now! Just click the green Buy button in the top-right corner of the model’s page. You can pay with PayPal or your Credit card.

Also, you may like Jason Bust 3D Printing Figurines as well as 3D Figurine of Villains.

_______
FAQ:

Where can I print a model if I have no printer?
How to get started with 3D printing?
How to set up my 3D printer?
How to choose right 3D model print bed positioning?
How to paint printed figurine?



This model was tested in Cura 3.3.1 and printed on an Ultimaker 2 in PLA material. Below you can find printing recommendations for Cura and Simplify3D softwares.

Cura printing recommendations:

Recommendations: For all parts of Locks you need to change "Brim" type to "Skirt" in Build Plate Adhesion section.

To avoid printing problems, we recommend the following settings:

Quality
Layer Height: 0.1 mm
Initial Layer Height: 0.3 mm
Line Width: 0.4 mm
 Wall Line Width: 0.4 mm
   Outer Wall Line Width: 0.4 mm
   Inner Wall(s) Line Width: 0.4 mm
 Top/Bottom Line Width: 0.4 mm
 Infill Line Width: 0.4 mm
 Skirt/Brim Line Width: 0.4 mm
Support Line Width: 0.4 mm
 Initial Layer Line Width: 100%

Shell
Wall Thickness: 0.8 mm
    Wall Line Count: 2
Outer Wall Wipe Distance: 0.2 mm
Top Surface Skin Layers: 0
Top/Bottom Thickness: 0.8 mm
   Top Thickness: 0.8 mm
      Top Layers: 8
    Bottom Thickness: 0.8 mm
      Bottom Layers: 8
Top/Bottom Pattern: Lines
Bottom Pattern Initial Layer: Lines
Top/Bottom Line Directions: [ ]
Outer Wall Inset: 0 mm
Compensate Wall Overlaps: Check
    Compensate Outer Wall Overlaps: Check
    Compensate Inner Wall Overlaps: Check
Fill Gaps Between Walls: Everywhere
Filter Out Tiny Gaps: Check
Horizontal Expansion: 0 mm
Initial Layer Horizontal Expansion: 0 mm
Z Seam Alignment: Sharpest Corner
Seam Corner Preference: Hide Seam
Ignore Small Z Gaps: Check
Extra Skin Wall Count: 1

Infill
Infill Density: 20%
Infill Line Distance: 4.0 mm
Infill Pattern: Grid
Infill Line Directions: [ ]
Infill X Offset: 0 mm
Infill Y Offset: 0 mm
Infill Overlap Percentage: 10%
    Infill Overlap: 0.04 mm
Skin Overlap Percentage: 5%
    Skin Overlap: 0.02 mm
Infill Wipe Distance: 0.1 mm
Infill Layer Thickness: 0.1 mm
Gradual Infill Steps: 1
Gradual Infill Steps Height: 1.5 mm
Infill Before Walls: Check
Minimum Infill Area: 0 mm2
Skin Removal Width: 0.8 mm
    Top Skin Removal Width: 0.8 mm
    Bottom Skin Removal Width: 0.8 mm
Skin Expand Distance: 0.8
    Top Skin Expand Distance: 0.8
    Bottom Skin Expand Distance: 0.8
Maximum Skin Angle for Expansion: 90˚
    Minimum Skin Width for Expansion: 0.0

Material
Initial Layer Flow: 100%
Enable Retraction: Check
Retraction Extra Prime Amount: 0 mm3
Retraction Minimum Travel: 0.8 mm
Maximum Retraction Count: 90
Minimum Extrusion Distance Window: 6.5 mm
Nozzle Switch Retraction Distance: 16 mm
Nozzle Switch Retraction Speed: 20 mm/s
    Nozzle Switch Retract Speed: 20 mm/s
    Nozzle Switch Prime Speed: 20 mm/s

Speed
Print Speed: 45 mm/s
    Infill Speed: 50 mm/s
    Wall Speed: 22.5 mm/s
      Outer Wall Speed: 22.5 mm/s
      Inner Wall Speed: 45 mm/s
    Top/Bottom Speed: 15 mm/s
Travel Speed: 60 mm/s
Initial Layer Speed: 22.5 mm/s
  Initial Layer Print Speed: 22.5 mm/s
  Initial Layer Travel Speed: 30 mm/s
Skirt/Brim Speed: 30 mm/s
Maximum Z Speed: 0 mm/s
Number of Slower Layers: 2

Travel
Combing Mode: All
Avoid Printed Parts when Traveling: Check
Travel Avoid Distance: 0.625 mm
Layer Start X: 0.0 mm
Layer Start Y: 0.0 mm

Cooling
Enable Print Cooling: Check
Fan Speed: 100%
    Regular Fan Speed: 100%
    Maximum Fan Speed: 100%
Regular/Maximum Fan Speed Threshold: 10 s
Initial Fan Speed: 0%
Regular Fan Speed at Height: 0.3 mm
    Regular Fan Speed at Layer: 2
Minimum Layer Time: 5 s
Minimum Speed: 10 mm/s

Support
Generate Support: Check
Support Placement: Everywhere
Support Overhang Angle: 60°
Support Pattern: Zig Zag
Connect Support ZigZags: Check
Support Density: 15 %
    Support Line Distance: 1.3333 mm
Support Z Distance: 0.3 mm
    Support Top Distance: 0.3 mm
    Support Bottom Distance: 0.3 mm
Support X/Y Distance: 1 mm
Support Distance Priority: Z overrides X/Y
Minimum Support X/Y Distance: 0.25 mm
Support Stair Step Height: 0.3 mm
Support Stair Step Maximum Width: 5.0 mm
Support Join Distance: 2.0 mm
Support Horizontal Expansion: 0.2 mm
Support Infill Layer Thickness: 0.1 mm
Gradual Support Infill Steps: 0
Use Towers: Check
Tower Diameter: 3.0 mm
Minimum Diameter: 3.0 mm
Tower Roof Angle: 65°

Build Plate Adhesion
Build Plate Adhesion Type: Brim (for all parts of locks use "Skirt")
Skirt/Brim Minimum Length: 250 mm
Brim Width: 8.0 mm
    Brim Line Count: 18
Brim Only on Outside: Check

Mesh Fixes
Union Overlapping Volumes: Check
Merged Meshes Overlap: 0.15 mm

Special Modes
Print Sequence: All at Once
Surface Mode: Normal

Experimental
Slicing Tolerance: Middle
Maximum Resolution: 0.01 mm
Flow rate compensation max extrusion offset: 0 mm
Flow rate compensation factor: 100%

Disclaimer: This model will look outstanding if printed on SLA/SLS 3D printer. The accuracy of the model printed on FFF printer can vary from the result shown in the pictures.

Simplify3D printing recommendations:

This model was tested with PLA material.

To avoid printing problems, we recommend the following settings:

Extruder
Nozzle Diameter: 0.4 mm
Extrusion Multiplier: 0.97
Extrusion Width: Auto

Retraction Distance: 5.00 mm
Extra Restart Distance: 0.00 mm
Retraction Vertical Lift: 0.08 mm
Retraction Speed: 5400.0 mm/min

Wipe Distance: 5.00 mm

Layer
Primary Layer Height: 0.2 mm
Top Solid Layers: 8
Bottom Solid Layers: 5
Outline/Perimeter Shells: 2
Outline Direction: Inside-Out

First Layer Height: 90%
First Layer Width: 100%
First Layer Speed: 20%

Additions
Use Skirt/Brim: Check
Skirt Layers: 1
Skirt Offset from Part: 6.00 mm
Skirt Outlines: 5

Infill
Internal Fill Pattern: Fast Honeycomb
External Fill Patern: Rectilinear
Interior Fill Percentage: 10%
Outline Overlap: 22%
Infill Extrusion Width: 100%
Minimum Infill Length: 5.00 mm
Combine Infill Every: 1 layers

External Infill Angle Offsets: 45/-45 deg

Support
Generate Support Material: Check
Support Infill Percentage: 15%
Extra Inflation Distance: 1.00 mm
Support Base Layers: 0
Combine Support Every: 1 layers

Dense Support Layers: 0
Dense Infill Percentage: 70%

Support Type: Normal
Support Pillar Resolution: 5.00 mm
Max Overhang Angle: 60 deg

Horizontal Offset From Part: 0.50 mm
Upper Vertical Separation Layers: 1
Lower Vertical Separation Layers: 1

Support Infill Angles: 45 deg

Temperature
Extruder 1 Temperature: 210
Heated Bed: 60

Cooling
Increase fan speed for layers below: 45.0 sec
  Maximum Cooling fan speed: 50%
Bridging fan speed override: 100%

Speeds
Default Printing Speed: 4800.0 mm/min
Outline Underspeed: 50%
Solid Infill Underspeed: 80%
Support Structure Underspeed: 80%
X/Y Axis Movement Speed: 10800.0 mm/min
Z Axis Movemen Speed: 1002.0 mm/min

Adjust printing speed for layers below: 15.0 sec
  Allow speed reduction down to: 20%

Other
Unsupported area threshold: 20.0 sq m
