Siege Tank 3D Printing Model | Assembly + Action

(20)
cm: 28.1 w x 32.2 d x 15.5 h
in: 11.063 w x 12.677 d x 6.102 h

Source Files

|

Description

|

Printing Details

This 3D model consists of files in StereoLithography (.Stl) format that have been optimized for 3D printing.

Before printing the files, we strongly recommend reading the PRINTING DETAILS section.

Version 1 and Version 2 are the STL files for Siege Tank 3D Model optimized for 3D printing, the preview pictures of which you see above.

It is recommended:

  • to print Version 1 STL files on FDM/FFF 3D printers;
  • to print Version 2 STL files on DLP/SLA/SLS 3D printers.
File Name File Size Time / Filament Object Size
(x/y/z mm)
1_hull_front (repaired).s tl
2.52 MiB 10 h 16 min 6 m 43 x 70 x 50 Download
3_hull_back (repaired).st l
3.52 MiB 11 h 2 min 6 m 43 x 75 x 50 Download
4_side_out_1_a (repaired) .stl
0.25 MiB 3 h 33 min 2 m 91 x 46 x 43 Download
5_side_out_2_a (repaired) .stl
0.40 MiB 8 h 36 min 7 m 91 x 49 x 40 Download
7_roll_big_1_a (repaired) .stl
0.02 MiB 1 h 30 min 1 m 42 x 42 x 27 Download
8_roll_small_1_a (repaire d).stl
0.02 MiB 53 min 1 m 24 x 24 x 27 Download
9_cat_1_a (repaired).stl
0.79 MiB 3 h 60 min 2 m 95 x 49 x 27 Download
10_joint_1 (repaired).stl
0.71 MiB 35 min <1 m 14 x 14 x 37 Download
13_side_out_1_c (repaired ).stl
0.25 MiB 3 h 33 min 2 m 91 x 46 x 43 Download
14_side_out_2_c (repaired ).stl
0.40 MiB 8 h 36 min 7 m 91 x 49 x 40 Download
16_roll_big_1_c (repaired ).stl
0.02 MiB 1 h 30 min 1 m 42 x 42 x 27 Download
17_roll_small_1_c (repair ed).stl
0.02 MiB 53 min 1 m 24 x 24 x 27 Download
18_cat_1_c (repaired).stl
0.79 MiB 3 h 60 min 2 m 95 x 49 x 27 Download
19_joint_3 (repaired).stl
0.71 MiB 35 min <1 m 14 x 14 x 37 Download
22_side_out_1_b (repaired ).stl
0.25 MiB 3 h 34 min 2 m 91 x 46 x 43 Download
23_side_out_2_b (repaired ).stl
0.40 MiB 8 h 37 min 7 m 91 x 49 x 40 Download
25_roll_big_1_b (repaired ).stl
0.02 MiB 1 h 30 min 1 m 42 x 42 x 27 Download
26_roll_small_1_b (repair ed).stl
0.02 MiB 53 min 1 m 24 x 24 x 27 Download
27_cat_1_b (repaired).stl
0.79 MiB 3 h 60 min 2 m 95 x 49 x 27 Download
28_joint_2 (repaired).stl
0.71 MiB 35 min <1 m 14 x 14 x 37 Download
31_side_out_1_d (repaired ).stl
0.25 MiB 3 h 34 min 2 m 91 x 46 x 43 Download
32_side_out_2_d (repaired ).stl
0.40 MiB 8 h 37 min 7 m 91 x 49 x 40 Download
34_roll_big_1_d(repaired) .stl
0.02 MiB 1 h 30 min 1 m 42 x 42 x 27 Download
35_roll_small_1_d (repair ed).stl
0.02 MiB 53 min 1 m 24 x 24 x 27 Download
36_cat_1_d (repaired).stl
0.79 MiB 3 h 60 min 2 m 95 x 49 x 27 Download
37_joint_4 (repaired).stl
0.71 MiB 35 min <1 m 14 x 14 x 37 Download
40_lifter_6_a (repaired). stl
0.08 MiB 55 min 1 m 32 x 42 x 9 Download
41_lifter_5_a (repaired). stl
0.10 MiB 25 min <1 m 13 x 24 x 17 Download
42_lifter_4_a (repaired). stl
0.08 MiB 32 min <1 m 46 x 18 x 10 Download
43_lifter_3_a (repaired). stl
0.03 MiB 26 min <1 m 40 x 15 x 10 Download
44_lifter_2_a (repaired). stl
0.03 MiB 19 min <1 m 26 x 20 x 10 Download
45_lifter_1_a (repaired). stl
0.06 MiB 17 min <1 m 9 x 22 x 10 Download
46_lifter_6_b (repaired). stl
0.08 MiB 55 min 1 m 32 x 42 x 9 Download
47_lifter_5_b (repaired). stl
0.10 MiB 25 min <1 m 13 x 24 x 17 Download
48_lifter_4_b (repaired). stl
0.08 MiB 32 min <1 m 46 x 18 x 10 Download
49_lifter_3_b (repaired). stl
0.03 MiB 26 min <1 m 40 x 15 x 10 Download
50_lifter_2_b (repaired). stl
0.03 MiB 19 min <1 m 26 x 20 x 10 Download
51_lifter_1_b (repaired). stl
0.06 MiB 17 min <1 m 9 x 22 x 10 Download
52_door_a (repaired).stl
0.05 MiB 1 h 1 m 52 x 30 x 10 Download
54_roll_center_1_a (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
55_roll_center_2_a (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
56_roll_center_3_a (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
57_roll_center_4_a (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
58_cat_center_a (repaired ).stl
0.65 MiB 5 h 23 min 2 m 96 x 41 x 27 Download
59_side_center_int_a (rep aired).stl
0.17 MiB 1 h 31 min 1 m 92 x 37 x 16 Download
60_door_b (repaired).stl
0.05 MiB 1 h 1 m 52 x 30 x 10 Download
62_roll_center_1_b (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
63_roll_center_2_b (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
64_roll_center_3_b (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
65_roll_center_4_b (repai red).stl
0.03 MiB 25 min <1 m 13 x 13 x 28 Download
66_cat_center_b (repaired ).stl
0.65 MiB 5 h 23 min 2 m 96 x 41 x 27 Download
67_side_center_int_a (rep aired).stl
0.17 MiB 1 h 31 min 1 m 92 x 37 x 16 Download
68_turret_5_R (repaired). stl
0.29 MiB 1 h 24 min 1 m 62 x 21 x 23 Download
69_turret_5_L (repaired). stl
0.29 MiB 1 h 23 min 1 m 62 x 21 x 23 Download
70_turret_4_R (repaired). stl
0.52 MiB 3 h 48 min 2 m 43 x 17 x 83 Download
71_turret_4_L (repaired). stl
0.52 MiB 3 h 48 min 2 m 43 x 17 x 83 Download
72_turret_2 (repaired).st l
0.62 MiB 5 h 54 min 4 m 89 x 24 x 99 Download
73_turret_1 (repaired).st l
0.64 MiB 21 h 17 min 14 m 115 x 107 x 41 Download
83_Ge_connector_x46.stl
0.05 MiB 6 min <1 m 20 x 5 x 5 Download
2_hull_center_NEW (repair ed).stl
5.05 MiB 44 h 15 min 33 m 191 x 102 x 50 Download
74_turret_3_NEW (repaired ).stl
0.23 MiB 2 h 60 min 2 m 89 x 19 x 33 Download
75_hull_1_half_1_NEW (rep aired).stl
2.62 MiB 16 h 50 min 10 m 102 x 50 x 95 Download
76_hull_1_half_2_NEW (rep aired).stl
2.65 MiB 16 h 53 min 10 m 102 x 50 x 96 Download
6_side_int_1_a (repaired) .stl
0.26 MiB 3 h 53 min 3 m 91 x 46 x 33 Download
15_side_int_1_c (repaired ).stl
0.26 MiB 3 h 53 min 3 m 91 x 46 x 33 Download
24_side_int_1_b (repaired ).stl
0.26 MiB 3 h 53 min 3 m 91 x 46 x 33 Download
33_side_int_1_d (repaired ).stl
0.26 MiB 3 h 53 min 3 m 91 x 46 x 33 Download
39_base_4 (repaired).stl
0.11 MiB 30 min <1 m 26 x 26 x 8 Download
38_claw_4 (repaired).stl
0.23 MiB 15 min <1 m 18 x 19 x 10 Download
30_base_2 (repaired).stl
0.11 MiB 30 min <1 m 26 x 26 x 8 Download
29_claw_2 (repaired).stl
0.23 MiB 15 min <1 m 18 x 19 x 10 Download
21_base_3 (repaired).stl
0.11 MiB 30 min <1 m 26 x 26 x 8 Download
20_claw_3 (repaired).stl
0.23 MiB 15 min <1 m 18 x 19 x 10 Download
12_base_1 (repaired).stl
0.11 MiB 30 min <1 m 26 x 26 x 8 Download
11_claw_1 (repaired).stl
0.23 MiB 15 min <1 m 18 x 19 x 10 Download
53-1_side_center_out_a (r epaired).stl
0.59 MiB 2 h 10 min 1 m 92 x 37 x 10 Download
53-2_rail_R (repaired).st l
0.02 MiB 24 min <1 m 35 x 23 x 7 Download
53-3_rail_L (repaired).st l
0.02 MiB 24 min <1 m 35 x 23 x 7 Download
61-1_side_center_out_b (r epaired).stl
0.59 MiB 2 h 10 min 1 m 92 x 37 x 10 Download
61-2_rail_R (repaired).st l
0.02 MiB 24 min <1 m 35 x 23 x 7 Download
61-3_rail_L (repaired).st l
0.02 MiB 24 min <1 m 35 x 23 x 7 Download
77_cat_a_only_for_flexibl e (repaired).stl
1.24 MiB 3 h 43 min 1 m 74 x 74 x 27 Download
78_cat_b_only_for_flexibl e (repaired).stl
1.24 MiB 3 h 43 min 1 m 74 x 74 x 27 Download
79_cat_c_only_for_flexibl e (repaired).stl
1.24 MiB 3 h 43 min 1 m 74 x 74 x 27 Download
80_cat_d_only_for_flexibl e (repaired).stl
1.24 MiB 3 h 43 min 1 m 74 x 74 x 27 Download
81_cat_center_a_(only_for _flexible) (repaired).stl
0.50 MiB 1 h 56 min 2 m 74 x 74 x 27 Download
82_cat_center_b_(only_for _flexible) (repaired).stl
0.50 MiB 1 h 56 min 2 m 74 x 74 x 27 Download
84_gofra_4x_only_for_flex ible (repaired).stl
0.55 MiB 25 min <1 m 26 x 26 x 23 Download
86_tube_x8 (repaired).stl
0.12 MiB 24 min <1 m 9 x 9 x 26 Download
85_Ge_connector_mini_8x ( repaired).stl
0.05 MiB 5 min <1 m 14 x 5 x 5 Download
...

HISTORY OF THE SIEGE TANK

"These new siege tanks work just like the old ones. When you put 'em in siege mode they get increased range and firepower. They can't move in siege mode, so if you need to reposition 'em, just switch 'em back into tank mode."
                                                                                                             - Chief Engineer Rory Swann

Siege tank is a fighting machine that gives to Terrans not only infantry support but also long-range firepower. This is not just a regular Tank to which we are accustomed. Its arsenal contains a huge set of weapons and he does not require support acting as a full-fledged killer on the battlefield. When it is in the "siege mode" the tank can not shoot at point-blank because of this it’s dead zone leaves the tank vulnerable to attacks by melee units. But this doesn’t prevent him from being the strongest ground weapon and, in combination with the MMM, can even overcome “Colossi". Even in the team, Siege Tanks show themselves very well. They do not shoot all together in one target, they kill in turns that do not allow the enemy to catch the tank on a recharge and destroy.

ABOUT THIS 3D MODEL

Siege Tank 3D model for printing was created in Autodesk MAYA. The model is saved in STL files, a format supported by most 3D printers.

All parts in this model are divided in a special way so that they will print with minimal use of support material.
The entire Tank is made with the maximum possible number of moving parts. It accurately repeats the movement of the model from the game on the basis of which author was taking inspiration.

FDM version features:
- Front and back tracks of this Tank can rise and rotate.
- You can print caterpillars with flexible material and they will be able to spin on your tank, thanks to the spinning wheels.
- Middle tracks made with a hidden doors that can be opened.
- Retractable-prefabricated lifters which you can put forward when the tank goes into siege mode.
- The tower turns at 360 degrees and has retractable guns.
- For this model, you will need 46 connectors. Since that all connectors are the same, you need to print one connector 46 times. You can find this file of connector under the name 83_Ge_connector_x46.stl
- The hull is available as divided into two pieces. 75 and 76 parts of this model are the same like part number 2. Its made for those who have small buildplate.
- For divided hull, you will need 4 connectors. If you will print solid part of hull than you will spend 42 connectors for this model.

SLS/SLA version features:
- less then FDM and made in two modes:

  1. Assault mode;
  2. Siege mode.

DLP/SLA/SLS Pre-supported 1.0 version features:
- Contains 1 file - all parts from DLP/SLA/SLS 1.0 are pre-supportedhollowed out, and have drain holes where needed;

All .STL files for 3D printing have been checked in Netfabb and no errors were shown.

Note: This model contains 46 connectors! You can find 1 file of the connector (83_Ge_connector_x46.stl) which you need to print 46 times.
Before starting 3D printing the model, read the Printing Details for CURA 2.7.0. software.

There are 82 + 46(connectors) parts for FDM version and 4 parts for SLS/SLA.

All parts of connectors should be printed at 100% infill.

Scale:
Its length in real life is 19320 mm in siege mode and 18660 in assault mode. Model made as 1/60 scale in FDM version and 1/100 in SLS/SLA version.

FDM version dimensions:

- After being printed will stand 155 mm tall, 281 mm wide, 322 mm deep - In Siege Mode.
95 mm tall, 213 mm wide, 311 mm deep - In Assault Mode.

- Connectors should be printed at 100% infill to make them solid.

SLS/SLA version dimensions:
- After being printed will stand 52 mm tall, 109 mm wide, 112 mm deep - In Siege Mod.
37 mm tall, 83 mm wide, 121 mm deep - In Assault Mod.

- Has few details to keep printing costs down.

WHAT WILL YOU GET AFTER PURCHASE?

- .STL files of Siege Tank for printing which consist of 87 parts.

- Movable tracks, caterpillars, wheels, lifters and tower.

- Siege Tank can be in two poses: Siege and Assault.
- Divided hull in two pieces for small buildplate.

- Made in scale 1/60 for FDM version and 1/100 for SLS/SLA of Its real size.

- Detailed settings that we provide for Cura 2.7.0 for the best print.

- High-poly detailed model of Siege Tank.

- Full technical support from the Gambody Support Team.

Watch the tutorial video on how to assemble Siege Tank 3D Printing Model at Gambody YouTube channel

Watch the video about Siege Tank 3D Printing Model at Gambody YouTube channel

You can get StarCraft Siege Tank Model for 3D Printing right now! Just click the green Buy button in the top-right corner of the model’s page. You can pay with PayPal or your credit card.

Also, you may like another StarCraft 3D models.

________________________

On 21.12.2017 the model files for Version 1 (FDM/FFF 3D printers) have been optimized.

Here is the list of updated files:

* 53-1_side_center_out_a (repaired)  \
* 53-2_rail_R (repaired);                       | instead (53_side_center_out_a)
* 53-3_rail_L (repaired);                      /
* 61-1_side_center_out_b (repaired); \
* 61-2_rail_R (repaired);                       | instead (61_side_center_out_b)
* 61-3_rail_L (repaired);                      /
* 77_cat_a_only_for_flexible (repaired)
* 78_cat_b_only_for_flexible (repaired)
* 79_cat_c_only_for_flexible (repaired)
* 80_cat_d_only_for_flexible (repaired)
* 81_cat_center_a_(only_for_flexible) (repaired)
* 82_cat_center_b_(only_for_flexible) (repaired)
* 84_gofra_4x_only_for_flexible (repaired) - Need to print 4 times.
* 85_Ge_connector_mini_8x (repaired) - Need to print 8 times.
* 86_tube_x8 (repaired) - Need to print 8 times.

STL files are already available for download in “Source files” tab for Version 1 (FDM/FFF 3D printers). You can find them at the end of the list.

_______
FAQ:

Where can I print a model if I have no printer?
How to get started with 3D printing?
How to set up my 3D printer?
How to choose right 3D model print bed positioning?
How to paint printed figurine?

This model was tested in Cura 2.7.0. and printed on an Ultimaker 2 in PLA material.

Note: For this model, you need 46 connectors. You can find one file of the connector (83_Ge_connector_x46.stl) which you need to print 46 times. All connectors should be printed at 100% infill to make them solid.

To avoid printing problems, we recommend the following settings:

Quality
Layer Height: 0.1 mm
Initial Layer Height: 0.27 mm
Line Width: 0.35 mm
Wall Line Width: 0.35 mm
   Outer Wall Line Width: 0.35 mm
   Inner Wall(s) Line Width: 0.35 mm
   Top/Bottom Line Width: 0.35 mm
   Infill Line Width: 0.35 mm
   Skirt/Brim Line Width: 0.35 mm
   Support Line Width: 0.35 mm
 Initial Layer Line Width: 100%

Shell
Wall Thickness: 1.05 mm
Wall Line Count: 3
Outer Wall Wipe Distance: 0.2 mm
Top Surface Skin Layers: 0
Top/Bottom Thickness: 0.8 mm
   Top Thickness: 0.8 mm
      Top Layers: 8
    Bottom Thickness: 0.8 mm
      Bottom Layers: 8
Top/Bottom Pattern: Lines
Bottom Pattern Initial Layer: Lines
Top/Bottom Line Directions: [ ]
Outer Wall Inset: 0.025 mm
Compensate Wall Overlaps: Check
    Compensate Outer Wall Overlaps: Check
    Compensate Inner Wall Overlaps: Check
Fill Gaps Between Walls: Everywhere
Horizontal Expansion: 0 mm
Initial Layer Horizontal Expansion: 0 mm
Z Seam Alignment: Shortest
Ignore Small Z Gaps: Check

Infill
Infill Density: 20% (all connectors should be printed at 100% infill)
Infill Line Distance: 3.5 mm
Infill Pattern: Grid
Infill Line Directions: [ ]
Infill Overlap Percentage: 10%
    Infill Overlap: 0.035 mm
Skin Overlap Percentage: 5%
    Skin Overlap: 0.0175 mm
Infill Wipe Distance: 0.0875 mm
Infill Layer Thickness: 0.1 mm
Gradual Infill Steps: 0
Infill Before Walls: Check
Minimum Infill Area: 0 mm2

Material
Enable Retraction: Check
Retraction Extra Prime Amount: 0 mm3
Retraction Minimum Travel: 0.7 mm
Maximum Retraction Count: 90
Minimum Extrusion Distance Window: 6.5 mm
Nozzle Switch Retraction Distance: 20 mm
Nozzle Switch Retraction Speed: 20 mm/s
    Nozzle Switch Retract Speed: 20 mm/s
    Nozzle Switch Prime Speed: 20 mm/s

Speed
Print Speed: 45 mm/s
    Infill Speed: 45 mm/s
    Wall Speed: 36 mm/s
      Outer Wall Speed: 26 mm/s
      Inner Wall Speed: 36 mm/s
    Top/Bottom Speed 20 mm/s
    Support Speed: 26 mm/s
      Support Infill Speed: 26 mm/s
Travel Speed: 90 mm/s
Initial Layer Speed: 27 mm/s

    Initial Layer Print Speed: 27 mm/s
    Initial Layer Travel Speed: 54 mm/s
Skirt/Brim Speed: 27 mm/s
Maximum Z Speed: 0 mm/s
Number of Slower Layers: 2

Travel
Combing Mode: All
Avoid Printed Parts when Traveling: Check
Travel Avoid Distance: 0.6562 mm

Cooling
Enable Print Cooling: Check
Fan Speed: 100%
    Regular Fan Speed: 100%
    Maximum Fan Speed: 100%
Regular/Maximum Fan Speed Threshold: 10 s
Initial Fan Speed: 0%
Regular Fan Speed at Height: 0.27 mm
    Regular Fan Speed at Layer: 2
Minimum Layer Time: 5 s
Minimum Speed: 10 mm/s

Support
Enable Support: Check
Support Placement: Everywhere
Support Overhang Angle: 50°
Support Pattern: Zig Zag
Connect Support ZigZags: Check
Support Density: 15 %
    Support Line Distance: 2.3333 mm
Support Z Distance: 0.1 mm
    Support Top Distance: 0.1 mm
    Support Bottom Distance: 0.1 mm
Support X/Y Distance: 0.7 mm
Support Distance Priority: Z overrides X/Y
Minimum Support X/Y Distance: 0.2 mm
Support Stair Step Height: 0.3 mm
Support Stair Step Maximum Width: 5.0 mm
Support Join Distance: 2.0 mm
Support Horizontal Expansion: 0.2 mm
Support Infill Layer Thickness: 0.1 mm
Use Towers: Check
Tower Diameter: 3.0 mm
Minimum Diameter: 3.0 mm
Tower Roof Angle: 65°

Build Plate Adhesion
Build Plate Adhesion Type: Brim
Skirt/Brim Minimum Length: 250 mm
Brim Width: 8.0 mm
    Brim Line Count: 23
Brim Only on Outside: Check

Mesh Fixes
Union Overlapping Volumes: Check
Merged Meshes Overlap: 0.15 mm

Special Modes
Print Sequence: All at Once
Surface Mode: Normal

Experimental
Extra Skin Wall Count: 0

Disclaimer: This model will look outstanding if printed on SLA/SLS 3D printer. The accuracy of the model printed on FFF printer can vary from the result shown in the pictures.

Comments

comments powered by Disqus

Similar items

Browse more newly listed 3D printings
